Setting Up a TURN Server with Coturn

Nihesh Rachakonda•
turn-serverwebrtccoturnstunnat-traversal

TURN (Traversal Using Relays around NAT) servers are essential for WebRTC applications to work reliably across different network configurations. This guide will walk you through installing and configuring a TURN server using Coturn.

What is TURN?

TURN is a protocol that allows peers behind NATs or firewalls to communicate by relaying media through a server. It's often used alongside STUN servers for WebRTC applications.

Prerequisites

  • Ubuntu/Debian server (or similar Linux distribution)
  • Root or sudo access
  • Domain name with SSL certificate (Can get one using Let's Encrypt)
  • Public IP address

Step 1: Install Coturn

First, update your system and install Coturn:

sudo apt update
sudo apt upgrade -y
sudo apt install coturn -y

Step 2: Configure SSL Certificate

Install Certbot for Let's Encrypt certificates:

sudo apt install certbot -y
sudo certbot certonly --standalone -d your-domain.com

Replace your-domain.com with your actual domain name.

Set Proper Permissions for SSL Certificates

Coturn needs to read the SSL certificates, so set the correct ownership:

sudo chown turnserver:turnserver /etc/letsencrypt/live/your-domain.com/
sudo chown turnserver:turnserver /etc/letsencrypt/live/your-domain.com/*
sudo chmod 644 /etc/letsencrypt/live/your-domain.com/*.pem

Step 3: Configure Coturn

Create the configuration file:

sudo nano /etc/turnserver.conf

Add the following configuration (replace with your actual values):

# === REALM & AUTH ===
realm=your-domain.com
server-name=turn-server
lt-cred-mech
fingerprint

# === LISTENING CONFIGURATION ===
listening-port=3478
tls-listening-port=5349
listening-ip=0.0.0.0

# === CRITICAL FIX: RELAY & EXTERNAL IPs ===
relay-ip=YOUR_PRIVATE_IP
external-ip=YOUR_PUBLIC_IP/YOUR_PRIVATE_IP

# === CREDENTIALS ===
user=turnuser:securepassword123

# === CERTIFICATES ===
cert=/etc/letsencrypt/live/your-domain.com/fullchain.pem
pkey=/etc/letsencrypt/live/your-domain.com/privkey.pem

# === PORT RANGE ===
min-port=49152
max-port=65535

# === LOGGING ===
log-file=/var/log/turnserver/turn.log
verbose

# === SECURITY & BEHAVIOR ===
no-rfc5780
no-stun-backward-compatibility
response-origin-only-with-rfc5780
syslog
no-multicast-peers

# === CLI PASSWORD (IF REQUIRED) ===
cli-password=your-password

# === ALLOCATION TIMEOUT ===
stale-nonce=3600
bps-capacity=0

max-bps=3000000
user-quota=0
total-quota=0

Key Configuration Options Explained:

  • realm: Your domain name
  • relay-ip: Your server's private IP address
  • external-ip: Public IP followed by private IP (separated by slash)
  • user: Username and password for TURN authentication
  • cert/pkey: Paths to your SSL certificates

Step 4: Set Up Logging Directory

Create the log directory and set permissions:

sudo mkdir -p /var/log/turnserver
sudo chown turnserver:turnserver /var/log/turnserver

Step 5: Configure Firewall

Allow the necessary ports through your firewall:

sudo ufw allow 3478/tcp
sudo ufw allow 3478/udp
sudo ufw allow 5349/tcp
sudo ufw allow 5349/udp
sudo ufw allow 49152:65535/udp

Step 6: Start and Enable Coturn Service

sudo systemctl enable coturn
sudo systemctl start coturn
sudo systemctl status coturn

Step 7: Test Your TURN Server

You can test your TURN server using tools like Trickle ICE or command-line tools.

Using turnutils

sudo apt install turnutils -y
turnutils_uclient -t -u turnuser -w securepassword123 your-domain.com

Troubleshooting

Common Issues:

  1. Port binding errors: Check if ports are already in use
  2. Certificate errors: Ensure certificate paths are correct
  3. Connection failures: Verify firewall rules and IP configurations

Check logs:

sudo tail -f /var/log/turnserver/turn.log

Security Considerations

  • Use strong passwords for TURN credentials
  • Keep SSL certificates up to date
  • Monitor server logs for suspicious activity
  • Consider using a dedicated user for TURN operations

Usage in WebRTC Applications

In your WebRTC application, configure the ICE servers like this:

const iceServers = [
  {
    urls: "stun:stun.l.google.com:19302",
  },
  {
    urls: "turn:your-domain.com:5349",
    username: "turnuser",
    credential: "securepassword123",
  },
];

const peerConnection = new RTCPeerConnection({ iceServers });

Conclusion

Setting up a TURN server ensures your WebRTC applications work reliably across all network configurations. Coturn is a robust, open-source solution that handles the complexities of NAT traversal for you.

Remember to replace all placeholder values with your actual domain, IPs, and secure passwords before deploying to production!
