Setting Up Headscale: Self-Hosted Tailscale Control Server

Nihesh Rachakonda••7 min read
headscaletailscalevpnwireguardself-hostednetworkingmesh
Share:

Headscale is an open-source, self-hosted implementation of the Tailscale control server. It allows you to create your own private mesh VPN network without relying on Tailscale's cloud infrastructure. This guide walks through setting up Headscale and connecting Tailscale clients.

What is Headscale?

Headscale provides:

  • A self-hosted alternative to Tailscale's coordination server
  • Full control over your mesh network infrastructure
  • WireGuard-based secure networking
  • No dependency on third-party cloud services
  • Support for all major Tailscale clients

If you want the benefits of Tailscale's mesh VPN but need to keep everything on your own infrastructure, Headscale is the solution.

Prerequisites

  • Ubuntu/Debian server (or similar Linux distribution)
  • Root or sudo access
  • Domain name pointing to your server
  • SSL certificate (we'll use Let's Encrypt)
  • Open ports: 443 (HTTPS), 3478 (STUN)

Step 1: Install Headscale

Download and install the latest Headscale release:

HEADSCALE_VERSION="" # See above URL for latest version, e.g. "X.Y.Z" (NOTE: do not add the "v" prefix!)
HEADSCALE_ARCH="" # Your system architecture, e.g. "amd64"
wget --output-document=headscale.deb \
 "https://github.com/juanfont/headscale/releases/download/v${HEADSCALE_VERSION}/headscale_${HEADSCALE_VERSION}_linux_${HEADSCALE_ARCH}.deb"

Verify the installation:

headscale version

Step 2: Configure Nginx with SSL

Install Nginx and Certbot:

sudo apt update
sudo apt install nginx certbot python3-certbot-nginx -y

Create an Nginx config for Headscale:

sudo nano /etc/nginx/sites-available/headscale

Add the following configuration:

server {
    listen 80;
    server_name headscale.your-domain.com;

    location / {
        proxy_pass http://127.0.0.1:8080;
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection "upgrade";
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_buffering off;
        proxy_read_timeout 86400;
    }
}

Enable the site and obtain SSL certificate:

sudo ln -s /etc/nginx/sites-available/headscale /etc/nginx/sites-enabled/
sudo nginx -t
sudo systemctl reload nginx
sudo certbot --nginx -d headscale.your-domain.com

Certbot will automatically configure SSL and set up auto-renewal.

Step 3: Configure Headscale

Edit the configuration file:

sudo nano /etc/headscale/config.yaml

Here's a recommended configuration:

# Server configuration
server_url: https://headscale.your-domain.com
listen_addr: 127.0.0.1:8080
metrics_listen_addr: 127.0.0.1:9090

# gRPC settings
grpc_listen_addr: 127.0.0.1:50443
grpc_allow_insecure: false

# Database configuration
database:
  type: sqlite
  sqlite:
    path: /var/lib/headscale/db.sqlite

# TLS handled by Nginx reverse proxy
tls_cert_path: ""
tls_key_path: ""

# Noise protocol (required for newer clients)
noise:
  private_key_path: /var/lib/headscale/noise_private.key

# IP prefixes for your network
prefixes:
  v4: 100.64.0.0/10
  v6: fd7a:115c:a1e0::/48

# DERP configuration
derp:
  server:
    enabled: true
    region_id: 999
    region_code: "headscale"
    region_name: "Headscale Embedded DERP"
    stun_listen_addr: "0.0.0.0:3478"
    private_key_path: /var/lib/headscale/derp_server_private.key
    automatically_add_embedded_derp_region: true
    ipv4: YOUR_PUBLIC_IP
    ipv6: ""
  urls: []
  paths: []
  auto_update_enabled: true
  update_frequency: 24h

# Disable external DERP servers (optional, for full self-hosting)
# derp:
#   urls: []

# DNS configuration
dns:
  magic_dns: true
  base_domain: tailnet.your-domain.com
  nameservers:
    global:
      - 1.1.1.1
      - 8.8.8.8

# Log settings
log:
  format: text
  level: info

# Policy (ACLs) - optional
policy:
  mode: file
  path: ""

# Unix socket for CLI
unix_socket: /var/run/headscale/headscale.sock
unix_socket_permission: "0770"

Replace the following values:

  • headscale.your-domain.com with your actual domain
  • YOUR_PUBLIC_IP with your server's public IP address
  • tailnet.your-domain.com with your preferred MagicDNS base domain

Step 4: Create Required Directories

sudo mkdir -p /var/lib/headscale
sudo mkdir -p /var/run/headscale
sudo chown -R headscale:headscale /var/lib/headscale
sudo chown -R headscale:headscale /var/run/headscale

Step 5: Configure Firewall

Allow the necessary ports:

sudo ufw allow 'Nginx Full'
sudo ufw allow 3478/udp
sudo ufw reload

For cloud providers, ensure your security groups allow:

  • TCP: 80, 443 (HTTP/HTTPS via Nginx)
  • UDP: 3478 (STUN for DERP)

Step 6: Start Headscale

Enable and start the service:

sudo systemctl enable headscale
sudo systemctl start headscale
sudo systemctl status headscale

Check the logs for any errors:

sudo journalctl -u headscale -f

Step 7: Create a User

Headscale organizes devices by users. Create your first user:

sudo headscale users create myuser

List users:

sudo headscale users list

Step 8: Generate Pre-Authentication Keys

Pre-auth keys allow devices to join without manual approval:

# Create a reusable key (expires in 24 hours by default)
sudo headscale preauthkeys create --user myuser --reusable --expiration 24h

For a one-time use key:

sudo headscale preauthkeys create --user myuser --expiration 1h

List existing keys:

sudo headscale preauthkeys list --user myuser

Step 9: Connect Tailscale Clients

Linux Client

Install Tailscale:

curl -fsSL https://tailscale.com/install.sh | sh

Connect to your Headscale server:

sudo tailscale up --login-server https://headscale.your-domain.com --authkey YOUR_PREAUTH_KEY

Or without a pre-auth key (requires manual approval):

sudo tailscale up --login-server https://headscale.your-domain.com

Then approve the node on the server:

sudo headscale nodes register --user myuser --key nodekey:XXXXX

macOS Client

Install Tailscale from the App Store or via Homebrew:

brew install tailscale

Connect using the CLI:

tailscale up --login-server https://headscale.your-domain.com --authkey YOUR_PREAUTH_KEY

Windows Client

  1. Download Tailscale from tailscale.com/download
  2. Open PowerShell as Administrator
  3. Run:
tailscale up --login-server https://headscale.your-domain.com --authkey YOUR_PREAUTH_KEY

iOS and Android

For mobile devices, you'll need to use the web-based registration flow:

  1. Install Tailscale from the App Store or Play Store
  2. On your server, generate a registration URL:
sudo headscale nodes register --user myuser --key nodekey:XXXXX
  1. Open the Tailscale app and use the custom login server option

Step 10: Managing Nodes

List all connected nodes:

sudo headscale nodes list

Delete a node:

sudo headscale nodes delete --identifier NODE_ID

Rename a node:

sudo headscale nodes rename --identifier NODE_ID "new-hostname"

Move a node to a different user:

sudo headscale nodes move --identifier NODE_ID --user newuser

Step 11: Enable Exit Nodes (Optional)

To use a node as an exit node for routing all traffic:

On the exit node:

sudo tailscale up --login-server https://headscale.your-domain.com --advertise-exit-node

Approve the exit node on the server:

sudo headscale routes enable --route "0.0.0.0/0" --identifier NODE_ID
sudo headscale routes enable --route "::/0" --identifier NODE_ID

On client devices, use the exit node:

tailscale up --exit-node=EXIT_NODE_IP

Step 12: Configure Access Control (ACLs)

Create an ACL policy file:

sudo nano /etc/headscale/acl.json

Example policy allowing all users to communicate:

{
  "acls": [
    {
      "action": "accept",
      "src": ["*"],
      "dst": ["*:*"]
    }
  ],
  "tagOwners": {},
  "hosts": {}
}

Update the config to use the ACL file:

policy:
  mode: file
  path: /etc/headscale/acl.json

Restart Headscale:

sudo systemctl restart headscale

Troubleshooting

Connection Issues

Check if the server is reachable:

curl -I https://headscale.your-domain.com/health

Certificate Errors

Verify certificate validity:

openssl s_client -connect headscale.your-domain.com:443 -servername headscale.your-domain.com

Client Not Connecting

Check client logs:

# Linux
sudo journalctl -u tailscaled -f

# macOS
log stream --predicate 'subsystem == "com.tailscale.ipn.macos"'

DERP Connectivity

Test if DERP is working:

# On the server, check if STUN port is listening
sudo ss -tulpn | grep 3478

View Server Logs

sudo journalctl -u headscale -f --no-pager

Security Considerations

  • Keep Headscale updated to the latest version
  • Use strong, unique pre-auth keys
  • Set appropriate expiration times for pre-auth keys
  • Implement ACLs to restrict network access
  • Regularly audit connected nodes
  • Enable automatic certificate renewal
  • Consider running Headscale behind a reverse proxy for additional security

Conclusion

Headscale provides a powerful self-hosted alternative to Tailscale's coordination server. With this setup, you have complete control over your mesh VPN infrastructure while still benefiting from Tailscale's excellent client software and WireGuard's security.

The combination of Headscale's simplicity and Tailscale's cross-platform clients makes it an excellent choice for homelab enthusiasts, small teams, or organizations that need to keep their network infrastructure fully self-hosted.

Remember to keep your server updated, monitor your logs, and regularly backup your configuration and database!
